| Temperature range | –20° to +80 °C |
| Type pf protection | IP 65 (higher on request) |
| Housing | Aluminum profile with PA end caps |
| Interface | CAN-Bus |
| Protocol | Compatible with CAN-specification 2.0B (11-Bit und 29-Bit identifier supported) |
| Data rate | up to 500 kbit/s |
| Technology | Transceiver (bidirectional, half-duplex) |
| Frequency | 2,4 GHz ISM band (2,402-2,480 GHz utilized), UWB 3,1-10,6 GHz (802.15.4 compliant) |
| Output power | Adjustable up to 10 mW |
| Range | Depending on installation and environment |
| Supply voltage | 6 .. 36 V DC (automotive battery) |
| Power consumption | 80 mA @ 12 V DC |
| Weight | 170 g without antenna and cable |
| Size | 7.5 x 6.0 x 2.1/3.0 x 2.4 x 0.8 inch (length x width x height) |
